Hikvision DS-1280ZJ-TR13 Black Back Base

Description Hikvision DS-1280ZJ-TR13 Black Back Base Junction box Junction Box Aluminum Alloy Hikvision White Parameters Approx. 187 g (0.41 lb.) AppearanceHikvision White MaterialAluminum Alloy DimensionΦ 110 mm × 144.3 mm × 48 mm (Φ 4.33″ × 5.68″ × 1.89″) DescriptionJunction Box Feature  Adopts overall die-casting formation enables high intensity and reliability  Applied to both indoor and outdoor conditions  With cable outlet(s) Dimension Φ 110 mm (4.33″) Φ 70 mm (2.76″) 144.3 mm (5.68″) 48 mm (1.89″) 43.5 mm (1.71″) Available Model DS-1280ZJ-TR13 Parameter Model Parameters DS-1280ZJ-TR13 Junction Box Appearance Hikvision White Material Aluminium Alloy Dimension Φ 110 mm × 144.3 mm × 48 mm (Φ 4.33″ × 5.68″ × 1.89″) Weight Approx. 187 g (0.41 lb.) Notes  The junction box should be installed on a flat surface.  The waterproof rubber is necessary for the outdoor application.  The wall should be capable of supporting at least 3 times as much as the total weight of the camera, and the junction box.  The maximum load capacity of the junction box is 1 kg (2.20 lb.).
